Technical Details

• Tolerance ±20%
• Package / Case Radial
• Mounting Type Through Hole
• Operating Temperature -55°C ~ 105°C
• Applications EMI, RFI Suppression
• Lead Spacing 0.886" (22.50mm)
• Termination PC Pins
• Ratings X2
• Dielectric Material Polypropylene (PP), Metallized
• Voltage Rating - AC 275V
• Voltage Rating - DC 760V
• Height - Seated (Max) 0.571" (14.50mm)
• Capacitance 0.22 µF
• Size / Dimension 1.024" L x 0.256" W (26.00mm x 6.50mm)
