Technical Details

• Features Temperature Compensated
• Package / Case 4-SIP, Dual Ports, Same Side
• Output Type Wheatstone Bridge
• Mounting Type Through Hole
• Output 0 mV ~ 10 mV (5V)
• Operating Pressure ±0.07PSI (±0.5kPa)
• Pressure Type Differential
• Accuracy ±0.3%
• Operating Temperature -25°C ~ 85°C
• Termination Style PC Pin
• Voltage - Supply 5V
• Port Size Male - 0.08" (2.04mm) Tube, Dual
• Applications Board Mount
• Supplier Device Package 4-SIP
• Port Style Barbless
• Maximum Pressure ±3.61PSI (±24.92kPa)
