Technical Details

• Features Locked Rotor Sensor, Speed Sensor (Tach)
• Voltage - Rated 24VDC
• Size / Dimension Rectangular/Rounded - 172mm L x 151mm H
• Bearing Type Ball
• RPM 3200 RPM
• Air Flow 255.0 CFM (7.14m³/min)
• Width 51.00mm
• Weight 2.5 lbs (1.1 kg)
• Operating Temperature -4 ~ 158°F (-20 ~ 70°C)
• Termination 4 Wire Leads
• Approval Agency CE, cURus, TUV
• Ingress Protection IP56M - Dust Protected, Water Resistant
• Fan Type Tubeaxial
• Noise 56.0dB(A)
• Static Pressure 0.736 in H2O (183.3 Pa)
• Power (Watts) 21.4 W
