Technical Details

• Tolerance ±10%
• Features Low ESR
• Package / Case Axial
• Mounting Type Through Hole
• Operating Temperature -55°C ~ 105°C
• Applications DC Link, DC Filtering
• Termination PC Pins
• Dielectric Material Polypropylene (PP), Metallized
• Voltage Rating - AC 90V
• Voltage Rating - DC 160V
• Capacitance 1 µF
• ESR (Equivalent Series Resistance) 177 mOhms
• Size / Dimension 0.433" Dia x 1.142" L (11.00mm x 29.00mm)
