Technical Details

• Tolerance ±10%
• Package / Case Radial
• Mounting Type Through Hole
• Operating Temperature -55°C ~ 125°C
• Applications General Purpose
• Lead Spacing 1.083" (27.50mm)
• Termination PC Pins
• Dielectric Material Polyester, Metallized
• Voltage Rating - AC 200V
• Voltage Rating - DC 400V
• Height - Seated (Max) 0.827" (21.00mm)
• Capacitance 1 µF
• ESR (Equivalent Series Resistance) 1.768 Ohms
• Size / Dimension 1.201" L x 0.492" W (30.50mm x 12.50mm)
