Technical Details

• Tolerance ±10%
• Features Low ESR
• Package / Case Axial
• Mounting Type Through Hole
• Operating Temperature -55°C ~ 105°C
• Applications DC Link, DC Filtering
• Termination PC Pins
• Dielectric Material Polypropylene (PP), Metallized
• Voltage Rating - AC 200V
• Voltage Rating - DC 250V
• Capacitance 0.22 µF
• Size / Dimension 0.374" Dia x 0.807" L (9.50mm x 20.50mm)
