Technical Details

• Power (Watts) 10.00W
• Voltage - Rated 220 ~ 240VAC
• Size / Dimension Square - 120mm L x 120mm H
• Bearing Type Ball
• Current Rating (Amps) 0.060A
• RPM 2150 RPM
• Air Flow 72.0 CFM (2.02m³/min)
• Width 38.00mm
• Weight 1.2 lbs (550 g)
• Operating Temperature 14 ~ 158°F (-10 ~ 70°C)
• Voltage Range 185 ~ 245VAC
• Termination 2 Wire Leads
• Approval Agency CE, CUR, TUV, UL
• Fan Type Tubeaxial
• Noise 37.0dB(A)
• Static Pressure 0.090 in H2O (22.4 Pa)
• Material - Frame Aluminum
• Material - Blade Polybutylene Terephthalate (PBT)
• ECCN EAR99
• HTSUS 8414.59.6590
• Moisture Sensitivity Level (MSL) 1 (Unlimited)
• REACH Status REACH Unaffected
• RoHS Status ROHS3 Compliant
